Let every family enjoy convenient electric travel.
Trendy streamline design
One-step installation
Type 1 connector for American market
Interoperable with all major automobiles in
North American market
Wall-mount/Floor-stand
14-50P/6-50P NEMA input plugs
Three enclosure colors
Wifi Version optional
Anti-welding protection
CCID 20 leakage current protection
UL listed and certified with the highest
standards for electrical safety
| Datasheet | Model | AC-U09SXE5A01,AC-U09SXS5A01 |
| Input | Power Supply | Single Phase |
| Rated Voltage | 240V AC | |
| Rated Current | 40A | |
| Frequency | 60Hz | |
| Maximun Current | 40A | |
| Plug | NEMA 14-50P/NEMA 6-50P | |
| Output | Output Power | 9.6kW |
| Charge Outlet | Typel | |
| Cable Length | 5m/7m | |
| Housing Material | Plastic PC940 | |
| User Interface | LED Indicator | Green/Yellow/Red |
| Start Mode | Plug&Play | |
| Communication | WiFi | Optional |
| Secure and Safety |
Leakage Current Protection |
CCID 20 |
| Enclosure Rating | NEMA 4 | |
| Electrical Protection | Over current protection,Residual current protection.Surge protection,Ground protection.Over/Under colage protection.Over/Under frequency protection.Over temperature protection. | |
| Certification Standard | UL 2594.UL2231-1&-2 | |
| Environment | Limited Warranty | 2 years |
| Installation | Wall-mount/Pole-mount(Optional) | |
| Work Temperature | -30℃~+50℃ | |
| Work Humidity | 5%~9.5% | |
| Work Altitude | <2000m | |
| Package |
Product Dimension |
344*201*100mm(H*W*D) |
| Package Dimension | 430*330*315mm(H*W*D) | |
| Net Weight | 6kg | |
| Gross Weight | 8kg | |
| External Package | Carton |
